MiniRay14 Line Array
Key feature


MiniRay14  Line Array

? 3-Way, 2-Channel Driven

? Coaxial Mid-high Driver, HF Extension >18 kHz

? Maximum SPL 145 dB

? Hi-End Grade Crossover

? Preangle Adjustable Rigging Hardware


MVS28 SUB

? Dual 18" Direct-Radiating, Bass-Reflex Design

? Stack Full-Range On Sub Without Adapter Frame

? Extra-Large Port Reduces Air Turbulence Noise

? Frequency Extension Down To 30 Hz


MD2000-4V AMP

? 12000W Powerful Power Supply

? 4 x 2000W @ 8Ω Output

? Built-in DSP Highly Integrated

? Up To MAX +23 dBu






PDF

MiniRay14 DATASHEET Download

MiniRay14 QUICK USERGUIDE PDF Download

Parameters

MiniRay14 SPECIFICATION

Frequency Range (-10dB)：40 Hz - 18 kHz

MAX SPL：Hi 145 dB;  Lo 137 dB

Coverage：Horizontal 90°/ Vertical 0-7° Adjustable

Transducers：2 × 14” ND Woofer;

                       2 × 100 mm + 65 mm Coaxial ND Mid-Hi Driver

Impedance：Hi-Mid: 8Ω;  Low: 8Ω

Driving Mode: 3-Way Two Drive

Power (AES)：Hi-Low: 500 W; Low: 500 W

Cabinet：Baltic Birch Plywood, Black Polyurea Finish

Dimensions (W×H×D): 850 × 420 × 556 mm / 33.4 × 16.5 × 21.8 in

Weight：57 kg / 125 lbs


MVS28 SPECIFICATON

Frequency Range：25 Hz - 180 Hz

MAX SPL：140 dB SPL Peak

Coverage：Horizontal 360°/ Vertical 180°

Transducers：1 × 28” Ferrite Woofer

Impedance: 4 Ω

Driving Mode: Single Drive

Power (AES)：600 W

Cabinet：Baltic Birch Plywood, Black Polyurea Finish

Dimensions (W×H×D): 680 × 630 × 840 mm / 26.7 × 24.8 × 33.7 in

Weight：85.8 kg / 189.1 lbs


MD2000-4V SPECIFICATION

Channels：4-Channel

Output Power：4 x 1600 W @ 8Ω

Frequency Response：20 Hz - 35 kHz ±1 dB

SNR: Typical > 120 dB

THD+N (1W，1KHz) ：<0.003 %

Sampling Rate / Resolution: 96 kHz / 24 Bit

Filters：HPF / LPF / 10 Band PEQ / 512 Taps / FIR Filter / Dynamic EQ / Crossover Limiter

Control Interface：Port: ETH / USB; Software: PC;  Local: 5" Touchscreen

Rated Voltage: 100-240V / AC 50-60Hz

Dimensions (W×H×D): 482 x 88 x 487 mm / 18.98 x 3.46 x 19.17 in

Weight：11 kg / 24.2 lbs
