MiniC Line Array
Key feature

MiniC Column Line Array

? Ultra-lightweight, single-person assembly & transport

? Patented horn & waveguide

? Line array coaxial column speaker

? Long throw, up to 141dB SPL



MiniC-Sub

? 15" subwoofer with100mm voice coil delivers 1000W ultra-high power

? 20mm ultra-long linear excursion for greater dynamics

? Peak SPL output up to 135dB



MiniC-AMP

? High integration 4 in 4 out DSP amplifier

? Portable design, compact footprint

? PC control and 4” color touchscreen


PDF

MiniC SYS DATASHEET Download

MiniC SYS USERGUIDE Download

MiniC-Amp QUICK SETUP GUIDE Download

Parameters

MiniC Line Array SPECIFICATION

Frequency Range (-10dB)：130Hz-17kHz

MAX SPL：141dB SPL Peak

Coverage：Horizontal 100°/ Vertical 0-10° Adjustable

Transducers：3 × 5" Resin Cone Woofer + 44 mm Coaxial ND Compression Driver

Impedance: Hi 8Ω; Lo 8Ω

Driving Mode: 3-Way Single Drive

Power (AES)：Hi 180W; Lo 300W

Cabinet：9mmPE

Dimensions (W×H×D): 247×451×256mm 9.7×17.7×10 in

Weight：12.5kg / 27.5lbs



MiniC-Sub SPECIFICATION

Frequency Range (-10dB)：130Hz-17kHz

MAX SPL：135 dB SPL Peak

Coverage：Horizontal 360°/ Vertical 180°

Transducers：1 × 15" Paper Cone Woofer with 100 mm voice coil

Impedance: 4Ω

Power (AES): 1000W

Cabinet：Baltic Birch Plywood Enclosure

Dimensions (W×H×D): 446 × 568 ×565 mm / 17.6 × 22.3 × 22.44 in

Weight：29.9 kg / 66 lbs



MiniC-Amp SPECIFICATION

Output Power：4 × 1000 W @ 8Ω / 4 × 1800 W @ 4Ω

Frequency Response：20 Hz - 35 kHz ±1 dB

SNR: Typical＞110dB

THD+N (1W，1KHz): <0.003 %

Sampling Rate / Resolution: 96 kHz / 24 Bit

Filters：HPF / LPF / 10-Band PEQ / 512-Taps FIR Filter /

3-Band Dynamic EQ / Crossover Limiter

Control Interface：Port: ETH / USB; Software: PC;  Local: 4" Touchscreen

Rated Voltage: 100-240V / AC 50-60Hz

Dimensions (W×H×D): 374 × 230 × 181 mm / 14.7 × 9 × 7.1 in

Weight：8.6 kg / 19 lbs
