MiniRay3C  SPECIFICATION

Frequency Range (-10dB)：40 Hz - 18 kHz

MAX SPL：142 dB SPL Peak

Coverage：Horizontal 100°/ Vertical 0-10° Adjustable

Transducers：1 × 14”+ 100 mm + 65 mm Integrated Coaxial 3 Way Driver

Impedance: 8 Ω

Driving Mode: 3-Way Single Drive

Power (AES)：800 W

Cabinet：Baltic Birch Plywood, Black Polyurea Finish

Dimensions (W×H×D): 760 × 420 × 530 mm  29.7 × 16.5 × 21.8 in

Weight：45 kg / 99.2 lbs

Frequency Range：25 Hz - 180 Hz

MAX SPL：140 dB SPL Peak

Coverage：Horizontal 360°/ Vertical 180°

Transducers：1 × 18” Ferrite Woofer

Impedance: 4 Ω

Driving Mode: Single Drive

Power (AES)：1600 W

Cabinet：Baltic Birch Plywood, Black Polyurea Finish

Dimensions (W×H×D): 680 × 630 × 840 mm  26.7 × 24.8 × 33.7 in

Weight：85.8 kg / 189.1 lbs

AMP Module

Output Power：4 x 1600 W @ 8Ω

Frequency Response：20 Hz - 35 kHz ±1 dB

Rated Voltage: 100~240VAC50~60Hz

SNR: Typical > 120 dB

Dimensions (W×H×D): 490×90×485mm 19.29×3.54×19.09in

Weight：16.8 kg / 37 lbs

DSP Module

Input Impedance:  20 K?

Output Impedance: 100 ?

A/D Dynamic Range: 118 dB

D/A Dynamic Range: 118 dB

Max Input Level: 23 dBu

Max Output Level: 17 dBu

THD:≦0.004%

Frequency Response: 20 Hz~40 kHz

Crosstalk: ≦-102 dB

SNR: ≧113 dB

Noise Floor: ≦-96 dB

CMRR: 74dB

Dante Input Channels (Optional): 4

AES Digital Input Channels: 2

Analog Input Channels: 4

USB Control Port: 1

Network Control Port: 1
